Sand gravel pumps are designed to handle very large particles for gravel and dredging operations. Gravel pump is single-stage single-suction horizontal centrifugal pump, connected by belt. It is light, good anti-cavitation performance and easy to install.It is applied to conveying of sands, mud and slurry with bigger solid particles.
Payment :
TTProduct Origin :
ChianColor :
BluaShipping Port :
TianjinLead Time :
20 days| SPECIFICATIONS | ||||||
| HORIZONTAL SAND GRAVAL SLURRY PUMPS | Sand gravel pumps are designed to handle very large particles for gravel and dredging operations. Gravel pump is single-stage single-suction horizontal centrifugal pump, connected by belt. It is light, good anti-cavitation performance and easy to install.It is applied to conveying of sands, mud and slurry with bigger solid particles. | |||||
| WORKING RANGE | Discharge Diameters - 4″to 12″ (100mm to 300mm) Flow Rate to 4,100m3/h Head Range to 70m |
|||||
| FEATURES | ||||||
| IMPELLERS | Front and rear shrouds have pump out vanes that reduce recirculation and seal contamination. Optional castings of straight or semi-Francis vanes (from 3 to 8 vanes on certain sizes) offer wider hydraulic options in single sizes. | |||||
| NPSH | Exceptional NPSHr conditions due to large impeller eyes. | |||||
| EXPELLER SEAL | Be available with low flow water flush or zero flow (grease lubricated) options to provide exceptional sealing where water introduction to the seal is intolerable or limited. | |||||
| STUFFING BOX | Gland sealing with packing and lantern ring. | |||||
| BEARING ASSEMBLY | Bearing assembly is adoptable of cylindrical structure, it is easy to adjust the space between impeller and front liner. Can be removed completely when repaired. Bearing assembly use grease lubrication. | |||||
| BASE | A single piece base cradles the cartridge type bearing and shaft assembly. An external impeller adjustment mechanism is provided below the bearing housing for easy adjustment of impeller clearance. | |||||
| APPLICATIONS | Sand Gravel pumps are designed for handling the most difficult higher abrasive slurries, which contain too big solids, to be pumped by common pumps, suitable for delivering slurries in mining, explosive -sludge in metal melting, dredging in dredger and course of rivers, and other fields. | |||||
| Performance Data | |||||||||
| Pump | Material | Allowable | Clear Water Performance | Drive Type | |||||
| Max. | |||||||||
| Model | Power | ||||||||
| P(Kw) | |||||||||
| Liner | Impeller | Capacity Q | Head | Speed | Max. | ||||
| H(m) | N(r/min) | Efficiency | |||||||
| η(%) | |||||||||
| m³/h | l/s | ||||||||
| 6/4AJG | M | M | 52 | 187-36 | Oct-52 | 7-51 | 1400-600 | 58 | CV.CR.DC |
| 8/6AJG | M | M | 88 | 576-133 | 160-37 | 10-48 | 1400-800 | 60 | CV.CR.DC |
| 10/8AJG | M | M | 147 | 930-216 | 258-60 | 11-44 | 940-500 | 65 | CR.DC |
| 12/10AJG | M | M | 305 | 1512-360 | 420-100 | 11-58 | 850-400 | 70 | CR.DC |
| 14/12AJG | M | M | 643 | 3168-522 | 880-145 | 9.5-66 | 700-300 | 68 | CR.DC |
| 16/14AJG | M | M | 459 | 3024-900 | 840-250 | 14-45 | 500-300 | 70 | CR.DC |
| 8/6AJGH | M | M | 177 | 648-126 | 180-35 | 15-77 | 1050-500 | 71 | CR.DC |
| 10/8AJGH | M | M | 205 | 1091-324 | 303-90 | 19.2-56.5 | 800-500 | 72 | CR.DC |
| 12/10AJGH | M | M | 558 | 2232-618 | 620-170 | 28-77 | 700-450 | 73 | CR.DC |
