Vertical cantilevered sump slurry pump's design that features hard alloy wear parts or full elastomer protection on all submerged components. This allows this pump to be used in highly corrosive applications.
Payment :
TTProduct Origin :
ChianColor :
BluaShipping Port :
TianjinLead Time :
20 days| SPECIFICATIONS | ||||||
| VERTICAL SUMP SLURRY PUMP | Vertical cantilevered sump slurry pump's design that features hard alloy wear parts or full elastomer protection on all submerged components. This allows this pump to be used in highly corrosive applications. | |||||
| WORKING RANGE | Discharge Diameters - 40mm to 250mm Flow Rate to 1267m3/h Head Range to 40m |
|||||
| FEATURES | ||||||
| FULLY CANTILEVERED | Vertical Sump Slurry Pumps are cantilevered shaft type. | |||||
| IMPELLERS | Double suction semi-open impellers. | |||||
| BEARING ASSEMBLY | Our maintenance friendly bearing assembly has heavy duty roller bearings, robust bearing housings, and a massive shaft. | |||||
| CASING | The metal pumps have a heavy walled abrasive resistant chrome alloy casing. Rubber pumps have a molded rubber casing adhered to sturdy metal structures. | |||||
| LARGE PARTICLE | Large particle impellers are also available and enable passing unusually large solids. | |||||
| APPLICATIONS | Vertical Sump Slurry Pump is widely used in the industries of petrochemical, sewage treatment, papermaking and etc. Note: Approximate Performance for clear water is used for primary selection only. |
|||||
| Performance Data | |||||||||
| Pump | Material | Allowable | Clear Water Performance | Impeller | |||||
| Model | Liner | Impeller | Max. | Capacity Q | Head | Speed | Max. | Impeller | |
| Power | H(m) | N(r/min) | Efficiency | Diameter | |||||
| P(Kw) | m³/h | l/s | η(%) | D(mm) | |||||
| 40AJP | M | M | 15 | 19.44-43.2 | 5.4-12 | 4.5-28.5 | 1000-2200 | 40 | 188 |
| 40AJPR | RU | RU | 17.28-39.6 | 4.8-11 | 4.0-26 | 1000-2200 | 40 | ||
| 65AJP | M | M | 30 | 23.45-111 | 6.5-30.8 | 5-29.5 | 700-1500 | 50 | 280 |
| 65AJPR | RU | RU | 22.5-105 | 6.25-29.15 | 5.5-30.5 | 700-1500 | 51 | ||
| 100AJP | M | M | 75 | 54-289 | 15-80.3 | 5-35 | 500-1200 | 56 | 370 |
| 100AJPR | RU | RU | 64.8-479.16 | 18-79.2 | 7.5-36 | 600-1200 | 62 | ||
| 150AJP | M | M | 110 | 108-479.16 | 30-133.1 | 8.5-40 | 500-1000 | 52 | 450 |
| 200AJP | M | M | 110 | 189-891 | 52.5-247.5 | 6.5-37 | 400-850 | 64 | 520 |
| 250AJP | M | M | 200 | 261-1089 | 72.5-302.5 | 7.5-33.5 | 400-750 | 60 | 575 |
| 300AJP | M | M | 200 | 288-1267 | 80-352 | 6.5-33 | 350-700 | 50 | 610 |
